BM-9800 Non-Insulated Folding Doors
Description
BM-9800 is a non-insulated folding door system with top-hung operation and suitable for normal and large constructions. It offers sturdy and elegant solutions applied to middle-end projects, such as modern residences, office buildings, conference centers, hotels, restaurants and many other.
Advantages
- Easy machining and installation
- High performance in terms of wind resistance, air permeability and water tightness
- Sturdy structure with flawless and long-lasting operation
Generic
| THERMAL INSULATION | AESTHETICS | PANEL TYPE | PANEL | APPLICATIONS |
|---|---|---|---|---|
| No | relatively low sight line | top-hung | aluminium framed panel with glazing bead | modern residences, office buildings, conference centers, hotels, restaurants |
Technical Characteristics
| SASH WIDTH | GLAZING | MAIN GASKET | LOCKING | VISIBLE ALUMINIUM | MAXIMUM WEIGHT | MAXIMUM HEIGHT | MAXIMUM PANEL WIDTH |
|---|---|---|---|---|---|---|---|
| 50 mm | 24-32mm | Double EPDM | double locking latches | 143m | 125Kg per vent | 2.8m/td> | 1,1 m |
