Hinged non insulated system COMFORT BM-9400
Description
COMFORT BM9400 consists one of the most completed non-insulated casement systems, which can serve a wide range of different needs with satisfied performances.
Advantages
- Very good value for money
- Flexibility in construction
- Variety of solutions
- Variety of profile design
- Competitive manufacturing costs due to reduced fabrication time
- High functionality
Generic
| WINDOWS TYPES | THERMAL INSULATION | EXTERIOR SHAPES |
|---|---|---|
| Hinged | No | Curved, Flat |
Technical Characteristics
| FRAME DEPTH | SASH WEIGHT | MINIMUM VISIBLE ALUMINIUM FACE HEIGHT | MINIMUM VISIBLE ALUMINIUM FACE WIDTH AT THE CENTRAL VERTICAL COLUMN (INTERLOCKING PROFILE) | GLAZING TYPE | MAXIMUM GLAZING THICKNESS | MECHANISM | SEALING METHOD |
|---|---|---|---|---|---|---|---|
| 45 mm | up to 180 Kg | 104 mm | 153 mm | Single – Double – Triple | from 4 mm up to 39 mm | Euro-groove, Euro-nut | Perimetrical at 3 levels with EPDM gaskets |
Performance
| WATER TIGHTNESS | AIR PERMEABILITY | WIND LOAD RESISTANCE | SOUND REDUCTION |
|---|---|---|---|
| CLASS E750 | CLASS 4 | C5 | 36 dB |
Characteristics
| TYPES OF TYPOLOGY |
|---|
| For all tilt & turn typologies |
TYPOLOGIES
One sash tilt and turn
Τilt and turn with fix light on top
Τilt and turn with fanlight
Double tilt and turn window
Double tilt and turn with light
Double tilt and turn window with fixed light
Single sash tilt & turn with shutter
Double tilt and turn window with shutter
Hinged inwards entrance door with kick plate
Hinged outwards entrance door with kick plate
Double leaf action door
